Standard Belt Width
| mm | Inch | mm | Inch |
| 76 | 3.0 | 840 | 33.1 |
| 152 | 6.0 | 917 | 36.1 |
| 229 | 9.0 | 993 | 39.1 |
| 306 | 12.0 | ||
| 382 | 15.0 | ||
| 458 | 18.0 | ||
| 535 | 21.1 | ||
| 611 | 24.1 | ||
| 687 | 27.0 | ||
| 764 | 30.1 |
Permissible Tensile Strength
| Belt Material | POM |
| Pin Material | PP |
| HX100A | 13000N/m |
| HX100B | 13000N/m |
| HX100C | 13000N/m |
Sprockets for HX100 Series
| Item | Outer Dia | Pitch Dia | Bore C(mm) | |
| A(mm) | B(mm) | Square | Round | |
| 24 | 145.6 | 148.5 | 38*38 | 25 |
| 24 | 151.7 | 158.0 | 38*38 | 25 |
