43 Round-Head Convex Point Chain

A4-1

43 Round-Head Convex Point Chain

FL43-LB-YT-TD

Product Details

Chain Plate Ref Width Weight Radius R Min. Chain Plate Material Working Load(Max.) Pin Material
mm (Kg/m) mm N(21°C)
FL43-LB-YT-TD 43 0.59 R150 POM 2100 SUS201
Pitch(mm) Pin Diameter(mm) Curl Radius R(Min.)mm
25.4 4 RD70
